Description
The Revo Starter Hotside Pack is the best-value entry point into E3D's RapidChange Revo ecosystem. It pairs a 40W Revo HeaterCore with 0.4mm and 0.6mm brass Revo Nozzles, giving you tool-free nozzle changes in under 60 seconds with no hot tightening.
If you're just getting started with 3D printing, or mostly print materials such as PLA, PETG and ASA at standard speeds, this pack is ideal — the two included brass nozzles cover the most common nozzle sizes.
Key features
- Best-value entry point for Revo
- Tool-free nozzle changes in under 60 seconds
- Brass nozzles for everyday 3D printing
- 40W HeaterCore for rapid heat-up and cool-down, with PTC safety that reduces power as temperature climbs
Choosing your thermistor
Select the thermistor to match your printer's firmware:
- 104NT (E3D) — E3D's standard thermistor. The right choice for most printers and control boards where you can set the sensor type in firmware (thermistor #5 in Marlin).
- 100K (Creality) — matches the sensor that stock Creality firmware expects (thermistor #1 in Marlin), so it works on Creality machines without any firmware changes.
- 100K (Creality Sprite) — the Creality 100K HeaterCore made for Sprite extruders; pair it with the Revo Sprite coldside. 24V only.
Please note: the Creality options include a Creality-specific HeaterCore and are not suitable for other printer brands. Check your printer's power supply and choose the matching 12V or 24V option.
Complete your HotEnd
A hotside pack is one half of a Revo HotEnd. If you don't already own a Revo, pair this pack with a Revo coldside to complete the setup: Revo Six, Revo Creality (standard and Sprite), Revo Prusa or Revo Voron.
Specifications
- Voltage: 12V or 24V (Sprite option: 24V only)
- HeaterCore power: 40W
- Thermistor: 104NT (E3D, Marlin #5) or 100K NTC (Creality, Marlin #1)
- Nozzles: brass, 0.4mm and 0.6mm, for 1.75mm filament
- Maximum temperature: 300°C (brass nozzles)
- Compatible with: all RapidChange Revo coldsides (Creality options: Creality printers only)
Contents
- 1 x Revo Brass Nozzle 0.6mm
- 1 x Revo Brass Nozzle 0.4mm
- 1 x Revo HeaterCore 40W (selected voltage and thermistor)
Full installation guides and datasheets: E3D Revo HeaterCore documentation and E3D Revo Nozzle documentation.
